Name: Hdmi active Optical Fiber Cable 4k 8k
Brand: CHERRY CONNECTRONICS
Price: 1200.0 INR
Availability: InStock

Price 1200.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Hdmi active Optical Fiber Cable 4k 8k Specification

Conductor Shape
Round

Usage & Applications
Audio/Video Transmission over Long Distances >10m

Rated Temperature
-20C to +60C

Insulation
High quality insulation for signal integrity

Core Number
Multiple fiber and copper cores

Impedance
100 ohms

Diameter
Approx. 5mm

Operating Temperature
-20C to +60C

Dielectiric Strength
>2.5kV

Number of Conductor
19 (Standard HDMI configuration)

Tensile Strength
>100N

Weight
Approx. 150g (for 10m)

Conductor Type
Hybrid (Copper + Fiber)

Core Material
Glass Fiber + Copper

Install Type
Fixed/Mobile

Cable Type
HDMI AOC (Active Optical Cable)

Features
Active Optical Fiber Technology, Supports 4K and 8K Resolutions, High-Speed Data Transmission, EMI/RFI Resistance, Plug and Play, Lightweight and Flexible, Long Distance Signal Transmission, Durable Design

Locking Type
Standard HDMI non-locking

Product Type
Active Optical HDMI Cable

Length
Available in multiple lengths (customizable as per requirement)

Voltage
N/A (Passive device, uses HDMI signal voltage)

Insulation Material
PVC/LSZH (Low Smoke Zero Halogen) optional

Application
Home Theater, Conference Room Presentations, Gaming, Digital Signage, Medical Imaging, Broadcast Studios

Conductor Material
Copper + Optical Fiber

Jacket Material
PVC (Polyvinyl Chloride)

Storage Temperature
-25C to +70C

Connector Color
Gold-Plated

Shield Material
Aluminum Foil + Braided Shield

Jacket Color
Black

Dimension (L*W*H)
Depends on cable length; Connector approx. 45mm x 20mm x 10mm

Color
Black

Material
Fiber Optic/Copper Hybrid, PVC Jacket, Alloy Connectors

Size
Standard HDMI (Type A)

Bandwidth
Up to 48Gbps

Backward Compatibility
Compatible with all previous HDMI versions

Power Supply
No external power required (powered via HDMI source)

Signal Transmission Distance
Up to 100 meters without signal loss

Plug and Play
Yes, no software required

Support for Audio
Supports all HDMI audio formats including Dolby TrueHD, DTS-HD Master Audio

Connector Type
HDMI Type A Male to HDMI Type A Male

Supported Resolutions
4K (3840x2160) @ 60Hz, 8K (7680x4320) @ 60Hz

HDMI Version
HDMI 2.1

Chroma Subsampling
4:4:4, 4:2:2, 4:2:0 supported

Compliance
RoHS, CE, FCC

Anti-Interference
Excellent immunity to electromagnetic and radio-frequency interference

Fire Resistance
Yes, meets IEC standards

Signal Direction
Unidirectional (Source to Display)

HDR Support
Supports HDR10, Dolby Vision

Connector Housing Material
Aluminum Alloy

EDID/HDCP Support
Supports EDID, HDCP 2.2/2.3

About Hdmi active Optical Fiber Cable 4k 8k

Level up to 4K 120Hz or 8K with the Cable Matters Fiber Optic HDMI cable; HDMI 8K cable features an active chipset and fiber optics for full 8K and 120Hz resolution support at extended distances not possible with traditional cables.

Unmatched Signal Quality Over Long Distances

This HDMI active optical fiber cable ensures flawless audio and video delivery over stretches up to 100 meters, eliminating concerns of signal loss or electromagnetic interference. The hybrid copper and optical fiber conductor design maintains superior clarity and color integrity even in demanding environments.

Next-Generation HDR and Audio Support

Experience cutting-edge visuals with full HDR10 and Dolby Vision compatibility, along with rich, lossless audio through support for Dolby TrueHD and DTS-HD Master Audio formats. Chroma subsampling (4:4:4, 4:2:2, 4:2:0) guarantees extraordinary color depth and display vibrancy in every application.

Plug-and-Play Versatility in Diverse Settings

No external power or software is needed for installation-simply connect source to display for immediate use. Its lightweight, flexible build and wide operating temperature range make it ideal for permanent and mobile setups in homes, offices, studios, or medical facilities.

FAQ's of Hdmi active Optical Fiber Cable 4k 8k:

Q: How does the HDMI active optical fiber cable support long-distance transmission without signal loss?

A: The cable utilizes active optical fiber technology, which efficiently converts electrical HDMI signals to optical, allowing transmission distances up to 100 meters while preventing signal degradation and maintaining high-resolution quality.

Q: What are the key benefits of using this cable in professional and home environments?

A: This cable delivers 4K and 8K resolutions at 60Hz, robust EMI/RFI immunity, plug-and-play functionality, and supports all HDMI audio and HDR video formats. It's ideal for settings where superior image quality and reliability over long runs are essential, such as home theaters, conference rooms, and medical imaging suites.

Q: Where can this HDMI cable be effectively installed or used?

A: It is suitable for installations in home entertainment systems, professional AV setups in conference rooms, digital signage, gaming environments, medical imaging equipment, and broadcast studios, owing to its flexibility, fire resistance, and high durability.

Q: What is the process for setting up the cable, and does it require software or external power?

A: Installation is straightforward-simply connect the HDMI Type A connectors from the source device to the display. No external power supply or software configuration is required, as the cable is powered by the HDMI source itself.

Q: Which audio and video formats and technologies does this cable support?

A: The cable supports all HDMI audio formats, such as Dolby TrueHD and DTS-HD Master Audio. It also delivers video with HDR10 and Dolby Vision, supports chroma subsampling (4:4:4, 4:2:2, 4:2:0), and handles bandwidths up to 48Gbps for flawless 4K and 8K content.

Q: Is this cable backward compatible with older HDMI devices and standards?

A: Yes, the HDMI active optical fiber cable is backward compatible with all previous HDMI versions, allowing it to connect with older source and display equipment without any functionality loss.
