D Sub Connector

Name: D Sub Connector
Brand: CHERRY CONNECTRONICS
Price: 4.0 INR
Availability: InStock

Price 4.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

D Sub Connector Specification

Features
Durable metal shell, secure locking screws, multiple pin configurations, easy installation

Operating Temperature
-25C to 85C

Impedance
Not typically specified for D-sub connectors

Cable Type
Ribbon or multicore

Number of Conductor
Normally 9, 15, 25, or 37 pins

Dielectiric Strength
1000V AC/min

Weight
Approx. 15g to 45g depending on type

Conductor Type
Solid or stranded copper

Conductor Shape
Round

Locking Type
Thumbscrew/Hex nut locking

Usage & Applications
Signal and data transmission

Core Material
Copper

Tensile Strength
Greater than 400N (depends on cable)

Rated Temperature
-25C to 85C

Insulation
Thermoplastic insulator

Install Type
Panel mount or cable mount

Core Number
Single core (per conductor pin)

Diameter
Varies with cable, typically 5mm-8mm

Product Type
D-Sub Connector

Length
Variable, depends on model and cable type

Voltage
Typically up to 250V

Insulation Material
Polyethylene (PE) or Polyvinyl Chloride (PVC)

Application
Computers, data communication, industrial automation, instrumentation

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-40C to 85C

Connector Color
Silver or blue (depends on plating and design)

Shield Material
Steel or nickel-plated steel

Jacket Color
Black or gray

Dimension (L*W*H)
Varies by model (e.g., 30mm x 12mm x 15mm for standard 9-pin)

Material
Metal shell with plastic insulator

Color
Silver, Blue, Black

Size
Standard D-sub sizes: DE-9, DA-15, DB-25, DC-37

Mounting Type
Through hole, panel mount, or cable mount

Contact Plating
Gold or tin over nickel

Pin Configuration
Straight or right-angle pins available

Insulation Resistance
> 5000 M at 500V DC

Pin Contact Resistance
20 m

Gender
Male (plug) or Female (socket)

RoHS Compliance
Yes

Flame Retardancy
UL94V-0 for insulator

Current Rating
5A per contact max

About D Sub Connector

We are specialized in offering a wide range of D Sub Connector products. The D Sub Connector offered by us is sturdy in nature and ensure long lasting service life. The latest equipment and modern machines have been used while manufacturing these D Sub Connectors. These products are high on efficiency and offer optimized performance. The D Sub Connectors are easy to use, operate, as well as offer high level of performance without any hassles.

Features:

Easy installation
Durable
High performance

Premium Materials for Reliable Connections

Equipped with gold or tin over nickel contact plating, these D Sub Connectors offer excellent conductivity and durability while limiting resistance and preventing corrosion. Their robust construction ensures stability and consistent performance even under high current loads. The connectors are suitable for a wide range of industries, providing quality interconnect solutions.

Versatile Mounting and Configuration Options

Choose from through hole, panel mount, or cable mount designs, as well as straight or right-angle pins to accommodate specific layout requirements. This flexibility allows integration into various devices and equipment efficiently. Available in both male (plug) and female (socket) versions, these connectors are tailored for different applications and environments.

FAQ's of D Sub Connector:

Q: How can I mount the D Sub Connector for my application?

A: You can choose from through hole, panel mount, or cable mount options for installing the D Sub Connector. This versatility enables easy integration into printed circuit boards, panels, or cables, depending on your design and application requirements.

Q: What benefits does gold or tin over nickel contact plating provide?

A: Gold or tin over nickel plating ensures low contact resistance, excellent conductivity, and protects the contacts from oxidation and corrosion, prolonging connector life and maintaining consistent performance.

Q: When should I choose straight or right-angle pin configurations?

A: Select straight pins for standard, inline connections that require a direct board or cable approach. Right-angle pins are ideal for tight spaces or layouts where cables or boards run parallel to the mounting surface, optimizing space within your assembly.

Q: Where can I use these D Sub Connectors safely?

A: These connectors, certified with UL94V-0 flame retardancy and RoHS compliance, are suitable for use in environments demanding safety and eco-friendly components, such as industrial equipment, communication devices, and instrumentation.

Q: What is the maximum current rating per contact and why is it important?

A: Each contact is rated for up to 5A, which allows the connector to handle mid to high-power applications efficiently without risk of overheating or failure, supporting reliable performance in critical systems.

Q: How does the insulation resistance benefit my system's reliability?

A: With an insulation resistance greater than 5000 M at 500V DC, these connectors minimize leakage currents and the risk of short circuits, ensuring dependable operation even under demanding conditions.
